A Gauss posted a question on my from last year’s Utah Oracle User’s Group Training Days presentation. If I understood his question correctly, this should help him work with his legacy code. Honestly, as I wrote the example something Bryn Llewellyn said kept banging around in my head, “Just because we can, doesn’t mean we should.” He was speaking of writing poorly engineered code.

Sometimes, we don’t get the opportunity to re-factor existing code. That leaves us with writing wrappers that aren’t pretty or effective. A realization and preface to showing everyone how to accomplish these tasks, and perhaps a watch out warning if you choose this path. I suspect that there may be a better way but I don’t know their code tree.

Here’s the question, as I understand it. They’ve got a library function in PL/SQL that returns a system reference cursor and is principally consumed by an external Java program. This type of architecture is more or less an Adapter OOAD pattern that I wrote about here, over a year and a half ago. The question comes to how to you wrap this approach and make it work in PL/SQL natively too.

The answer depends on some earlier posts because I don’t have a great deal of time to write new examples. It uses a COMMON_LOOKUP table, which is more or less a bunch of small tables grouped into a big table for use in user interaction forms. That way the values don’t get lost in a large code base and are always consistently maintained. These types of tables exist in all major ERP and CRM applications.

The base code for the example is found here, where I discussed how you can effectively use object tables – collections of user-defined object types (Oracle 9iR2 forward if I remember correctly). You can grab the full code at the bottom of the page by clicking the Code Script widget to unfold the code. That code also depends on the Oracle Database 11g PL/SQL Programming downloadable code, which you can download by clicking the link to the zip file location.

Here are the steps to wrap a function that returns a PL/SQL reference cursor so that it can also return a PL/SQL associative array.

1. Create a package specification to hold all the components that are required to manage the process. Assuming that they may have anchored the system reference cursor to something other than a table like a shared cursor, which is a cumbersome implementation design. (I actually chose to exclude this from the book because it’s a stretch as a good coding practice. At least, it is from my perspective. Also, I couldn’t find an example in the Oracle documentation, which led me to believe they didn’t think it’s a great idea either or I could have glossed over it.) You should note that the PL/SQL RECORD, Associative Array (collection), and the REF CURSOR are defined in this package specification.

-- Create a package to hold the PL/SQL record structure.
CREATE OR REPLACE PACKAGE example IS

  -- Force cursors to be read as if empty every time.
  PRAGMA SERIALLY_REUSABLE;

  -- Package-level record structure that mimics SQL object type.
  TYPE common_lookup_record IS RECORD
  ( common_lookup_id      NUMBER
  , common_lookup_type    VARCHAR2(30)
  , common_lookup_meaning VARCHAR2(255));

  -- Package-level collection that mimics SQL object table.
  TYPE common_lookup_record_table IS TABLE OF common_lookup_record
  INDEX BY PLS_INTEGER;

  -- Cursor structure to support a strongly-typed reference cursor.
  CURSOR c IS
    SELECT   common_lookup_id
    ,        common_lookup_type
    ,        common_lookup_meaning
    FROM     common_lookup;

  -- Package-level strongly-typed system reference cursor.
  TYPE cursor_lookup IS REF CURSOR RETURN c%ROWTYPE;

END;
/

2. Write a function to return a strongly typed system reference cursor that’s anchored to a cursor defined in the package. This is fairly straightforward when the package specification is done right. You should notice right away that anchoring the original cursor in the package was a horrible practice because you must repeat it all again in the function. In my opinion, you shouldn’t anchor any system reference cursor explicitly to anything other than a table. The cursor could have used the generic weak cursor data type – SYS_REFCURSOR. Doing so, saves all the extra lines required by a potential shared cursor.

CREATE OR REPLACE FUNCTION get_common_lookup_cursor
( table_name VARCHAR2, column_name VARCHAR2)
RETURN example.cursor_lookup IS

  -- Define a local variable of a strongly-typed reference cursor.
  lv_cursor EXAMPLE.CURSOR_LOOKUP;

BEGIN

  -- Open the cursor from a static cursor
  OPEN lv_cursor FOR
    SELECT common_lookup_id
    ,      common_lookup_type
    ,      common_lookup_meaning
    FROM   common_lookup
    WHERE  common_lookup_table = table_name
    AND    common_lookup_column = column_name;

  -- Return the cursor handle.
  RETURN lv_cursor;

END;
/

3. Write a wrapper function that takes the reference cursor as a formal parameter and returns an Associative Array. You should note that this can’t be called from a SQL context. You must only use it in a PL/SQL context because system reference cursors are PL/SQL only data types.

CREATE OR REPLACE FUNCTION convert_common_lookup_cursor
( pv_cursor EXAMPLE.CURSOR_LOOKUP)
RETURN example.common_lookup_record_table IS

  -- Declare a local counter variable.
  counter INTEGER := 1;

  -- Local PL/SQL-only variable.
  out_record  EXAMPLE.COMMON_LOOKUP_RECORD;
  out_table   EXAMPLE.COMMON_LOOKUP_RECORD_TABLE;

BEGIN

  -- Grab the cursor wrapper and return values to a PL/SQL-only record collection.
  LOOP
    FETCH pv_cursor INTO out_record;
    EXIT WHEN pv_cursor%NOTFOUND;

    -- Assign it one row at a time to an associative array.
    out_table(counter) := out_record;

    -- Increment the counter.
    counter := counter + 1;

  END LOOP;

  -- Return the record collection.
  RETURN out_table;

END;
/

4. You can test the program in an anonymous block, like the one below. It defines a local Associative Array variable and then assigns the system reference cursor through the wrapper.

-- Open the session to see output from PL/SQL blocks.
SET SERVEROUTPUT ON

DECLARE

  -- Define a local associative array.
  process_table  EXAMPLE.COMMON_LOOKUP_RECORD_TABLE;

BEGIN
  -- Print title block.
  dbms_output.put_line('Converting a SYS_REFCURSOR to TABLE');
  dbms_output.put_line('---------------------------------------------------');

  -- Run the dynamic variables through the cursor generating function and then convert it.
  process_table := convert_common_lookup_cursor(get_common_lookup_cursor('ITEM','ITEM_TYPE'));

  -- Read the content of the Associative array.
  FOR i IN 1..process_table.COUNT LOOP
    dbms_output.put('['||process_table(i).common_lookup_id||']');
    dbms_output.put('['||process_table(i).common_lookup_type||']');
    dbms_output.put_line('['||process_table(i).common_lookup_meaning||']');
  END LOOP;

END;
/

I hope this answers Gauss’s question. While writing it, I could envision another question that might pop-up. How do you convert an object table type to a PL/SQL context. It was an omission not to include it in that original post on object table types. Here’s how you wrap an object table type into a PL/SQL scope collection.

You might have guessed. It’s done with another wrapper function. At least this is the easiest way to convert the SQL data type to a PL/SQL data type that I see. If you’ve another approach, a better way, let us know.

CREATE OR REPLACE FUNCTION get_common_lookup_record_table
( table_name  VARCHAR2
, column_name VARCHAR2 )
RETURN example.common_lookup_record_table IS

  -- Declare a local counter variable.
  counter INTEGER := 1;

  -- Define a dynamic cursor that takes two formal parameters.
  CURSOR c (table_name_in VARCHAR2, table_column_name_in VARCHAR2) IS
    SELECT   *
    FROM     TABLE(get_common_lookup_object_table(UPPER(table_name_in),UPPER(table_column_name_in)));

  -- A local PL/SQL-only collection variable.
  list EXAMPLE.COMMON_LOOKUP_RECORD_TABLE;

BEGIN

  -- Grab the cursor wrapper and return values to a PL/SQL-only record collection.
  FOR i IN c(table_name, column_name) LOOP
    list(counter) := i;
    counter := counter + 1;
  END LOOP;

  -- Return the record collection.
  RETURN list;
END get_common_lookup_record_table;
/

You can then test this in an anonymous block, like so:

-- Open the session to see output from PL/SQL blocks.
SET SERVEROUTPUT ON

DECLARE

  -- Declare a local PL/SQL-only collection and assign the value from the function call.
  list EXAMPLE.COMMON_LOOKUP_RECORD_TABLE;

  BEGIN

  -- Print title block.
  dbms_output.put_line('Converting a SQL Collection to a PL/SQL Collection');
  dbms_output.put_line('---------------------------------------------------');

  -- Assign wrapped SQL collection to a PL/SQL-only collection.
  list := get_common_lookup_record_table('ITEM','ITEM_TYPE');

  -- Call the record wrapper function.
  FOR i IN 1..list.COUNT LOOP
    dbms_output.put('['||list(i).common_lookup_id||']');
    dbms_output.put('['||list(i).common_lookup_type||']');
    dbms_output.put_line('['||list(i).common_lookup_meaning||']');
  END LOOP;

END;
/

As always, I hope this helps somebody without paying a fee for content.

A few of my students wanted me to post sample cursor loops, so here are examples of simple, FOR, and WHILE loops. There are a couple variations on approaches that demonstrate %TYPE and %ROWTYPE anchoring to data dictionary table definitions and local cursors.

Part of the idea behind these examples is to show the basic structure while mimicking the \G option of MySQL. The \G (Go) displays results as a list of column names and values by row. Ever since I discovered that in MySQL, I’ve hoped Oracle would incorporate something similar in their product. While discussing my wish list, I’d also like Oracle to make the FROM dual optional (like MySQL does) when selecting a string or numeric literal.

You can click any of the titles to view the code, which isn’t needed when you don’t have JavaScript enabled or the RSS expands them for you.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49

SET SERVEROUTPUT ON SIZE 1000000

DECLARE

  -- Declare local variables that are anchored to column data types.
  lv_title     item.item_title%TYPE;
  lv_subtitle  item.item_subtitle%TYPE;
  lv_rating    item.item_rating%TYPE;

  -- Declare a static cursor.
  CURSOR c IS
    SELECT   i.item_title AS title
	,        i.item_subtitle AS subtitle
	,        i.item_rating AS rating
	FROM     item i;

BEGIN
  -- Open the cursor.
  OPEN c;

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Start the simple loop block.
  LOOP

    -- Fetch a row of the cursor and assign it to the three local variables.
    FETCH c
    INTO  lv_title
    ,     lv_subtitle
    ,     lv_rating;

    -- Exit when there aren't any more records in the cursor, with this you loop infinitely.
    EXIT WHEN c%NOTFOUND;

    -- Print the local variables on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||lv_title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||lv_subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||lv_rating||']');

    -- Print an ending line.
   dbms_output.put_line('----------------------------------------------------------------------');

  END LOOP;

  -- Close the cursor and release the resources.
  CLOSE c;
END;
/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52

SET SERVEROUTPUT ON SIZE 1000000

DECLARE

  -- Declare a local record data type, with explicit data types (you could use %TYPE here too).
  TYPE title_type IS RECORD
  ( title     VARCHAR2(60)
  , subtitle  VARCHAR2(60)
  , rating    VARCHAR2(8));

  -- Declare a local variable of the local record structure data type.
  item_record TITLE_TYPE;

  -- Declare a static cursor.
  CURSOR c IS
    SELECT   i.item_title AS title
	,        i.item_subtitle AS subtitle
	,        i.item_rating AS rating
	FROM     item i;

BEGIN

  -- Open the cursor.
  OPEN c;

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Start the simple loop block.
  LOOP

    -- Fetch a row of the cursor and assign it to the local record structure variable.
    FETCH c
    INTO  item_record;

    -- Exit when there aren't any more records in the cursor, with this you loop infinitely.
    EXIT WHEN c%NOTFOUND;

    -- Print the local variable elements on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||item_record.title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||item_record.subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||item_record.rating||']');

    -- Print an ending line.
   dbms_output.put_line('----------------------------------------------------------------------');

  END LOOP;

  -- Close the cursor and release the resources.
  CLOSE c;
END;
/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46

SET SERVEROUTPUT ON SIZE 1000000

DECLARE

  -- Declare a static cursor.
  CURSOR c IS
    SELECT   i.item_title AS title
	,        i.item_subtitle AS subtitle
	,        i.item_rating AS rating
	FROM     item i;

  -- Declare a local variable of that inherits its structure from a local cursor.
  item_record c%ROWTYPE;

BEGIN

  -- Open the cursor.
  OPEN c;

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Start the simple loop block.
  LOOP

    -- Fetch a row of the cursor and assign it to the local record structure variable.
    FETCH c
    INTO  item_record;

    -- Exit when there aren't any more records in the cursor, with this you loop infinitely.
    EXIT WHEN c%NOTFOUND;

    -- Print the local variable elements on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||item_record.title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||item_record.subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||item_record.rating||']');

    -- Print an ending line.
   dbms_output.put_line('----------------------------------------------------------------------');

  END LOOP;

  -- Close the cursor and release the resources.
  CLOSE c;
END;
/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

SET SERVEROUTPUT ON SIZE 1000000

DECLARE

  -- Declare a static cursor.
  CURSOR c IS
    SELECT   i.item_title AS title
	,        i.item_subtitle AS subtitle
	,        i.item_rating AS rating
	FROM     item i;

BEGIN

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Start a cursor FOR loop block.
  FOR i IN c LOOP

    -- Print the local variable elements on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||i.title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||i.subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||i.rating||']');

    -- Print an ending line.
   dbms_output.put_line('----------------------------------------------------------------------');

  END LOOP;
END;
/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

SET SERVEROUTPUT ON SIZE 1000000

BEGIN

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Start a cursor FOR loop block with the static cursor in the definition.
  FOR i IN (SELECT   i.item_title AS title
	        ,        i.item_subtitle AS subtitle
	        ,        i.item_rating AS rating
	        FROM     item i) LOOP

    -- Print the local variable elements on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||i.title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||i.subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||i.rating||']');

    -- Print an ending line.
   dbms_output.put_line('----------------------------------------------------------------------');

  END LOOP;
END;
/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44

DECLARE

  -- Declare a static cursor.
  CURSOR c IS
    SELECT   i.item_title AS title
	,        i.item_subtitle AS subtitle
	,        i.item_rating AS rating
	FROM     item i;

  -- Declare a local variable of that inherits its structure from a local cursor.
  item_record c%ROWTYPE;

BEGIN

  -- Open the cursor.
  OPEN c;

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Fetch the first record to put into context the cursor attributes, like %FOUND.
  FETCH c INTO item_record;

  -- Start the simple loop block with a guard on entry condition.
  WHILE (c%FOUND) LOOP

    -- Print the local variable elements on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||item_record.title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||item_record.subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||item_record.rating||']');

    -- Print an ending line.
    dbms_output.put_line('----------------------------------------------------------------------');

    -- Fetch the second and subsequent rows of the cursor and assign it to a local variables.
    FETCH c
    INTO  item_record;

  END LOOP;

  -- Close the cursor and release the resources.
  CLOSE c;
END;
/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

DECLARE

  -- Declare a static cursor.
  CURSOR c IS
    SELECT   i.item_title AS title
	,        i.item_subtitle AS subtitle
	,        i.item_rating AS rating
	FROM     item i;

  -- Declare a local variable of that inherits its structure from a local cursor.
  item_record c%ROWTYPE;

BEGIN

  -- Open the cursor.
  OPEN c;

  -- Print a starting line.
  dbms_output.put_line('----------------------------------------------------------------------');

  -- Start the simple loop block with a guard on entry condition.
  WHILE (TRUE) LOOP

    FETCH c INTO item_record;
    EXIT WHEN c%NOTFOUND;

    -- Print the local variable elements on a single line each to mimic MySQL \G equivalent.
    dbms_output.put_line('ITEM.ITEM_TITLE    ['||item_record.title||']');
    dbms_output.put_line('ITEM.ITEM_SUBTITLE ['||item_record.subtitle||']');
    dbms_output.put_line('ITEM.ITEM_RATING   ['||item_record.rating||']');

    -- Print an ending line.
    dbms_output.put_line('----------------------------------------------------------------------');

  END LOOP;

  -- Close the cursor and release the resources.
  CLOSE c;
END;
/

I’m sure this will help my students and hope it helps somebody else.

Installed Zend Community Edition on Windows 7 64-bit. It worked easily. You just need to remember to install the JSDK 32-bit version for the Java Bridge. Clear notation about phpMyAdmin and MySQL being separate downloads has been added to the new Zend Community Edition Server (4.0.6), and it clearly does support Windows 7.

If you plan on installing MySQL and Oracle, I would recommend you install MySQL after you install Oracle and the Zend Community Server. However, it doesn’t matter because both ways work.

That completes my WAMP (Windows, Apache, MySQL, Perl, PHP, or Python) and OPAW (Oracle, Perl, PHP, or Python, Apache, Windows) installations. Actually, I’m not sure there is an OPAW acronym for a LAMP stack running Oracle on a Windows platform. OPAL is the acronym for a LAMP stack running an Oracle database, but I’ve never seen one before for Windows. Therefore, I created one.

My two cents worth …

I’d vote for clearer guidance on these acronyms. After all, they’re only purpose appears to be how to market variants of LAMP. The variants that I’ve seen for LAMP (Linux) are: MAMP (Mac OS X), SCAMP (Santa Cruz Operation), SAMP (Solaris), OAMP (OpenBSD, and WAMP (Windows) for MySQL database versions. The key seems to be swapping the first letter. I’ve only seen OPAL (Linux) officially for a LAMP stack that uses an Oracle database on a Linux platform. While my OPAW leverages what I perceive as a possible pattern, it may be wrong. Does anybody know what the right way to label these is?

I just wanted to see how Zend Server Community Edition might be broken. Performing a full feature install on Windows x64, I confirmed that Zend Server’s Java Bridge depends on the 32-bit JRE (common sense prevails). Installing it against the JRE 64-bit jvm.dll did raised an exception but none of the instructions address the problem.

It’s one of those simplifying assumptions – everybody knows 32-bit software works with 32-bit software. Anybody running on Windows XP x64 should know that they may need a JDK 64-bit and both a JRE 64-bit and JRE 32-bit for some applications. For those who don’t know this, like my students and other newbies, when you run Windows XP the 64-bit stuff goes in the C:\Program Files directory and the 32-bit stuff goes in the C:\Program Files (x86) directory. This lets you develop 32-bit or 64-bit Java applications on the same 64-bit machine.

Another tidbit of interest, don’t choose a full install if you’ve already installed MySQL. The Zend Community Server isn’t smart enough to alter the configuration to another port, and their my.ini points to a 3306 listener port. This causes the MySQL_ZendServer51 service to fail. It also doesn’t uninstall well. If you don’t want to clean the Windows Registry, don’t choose to install a second MySQL.

As an FYI, the Zend installation of MySQL doesn’t put a password on the root account. Don’t forget to add one after the install if you go down the full product road. This has the Zend Server Community Edition installation instructions.

I saw a post in the OTN forum that asked a simple question and had no simple example as an answer, so I thought it would be nice to provide one. Basically, somebody wanted to know how to call into a stored procedure and return a value with more or less one pass-by-value and another pass-by-reference variable.

This defines a simple echo procedure, which takes a message and returns a formatted message:

1
2
3
4
5
6
7

CREATE OR REPLACE PROCEDURE echo
( message IN     VARCHAR2
, reply      OUT VARCHAR2 ) IS
BEGIN
  reply := 'Message ['||message||'] received.';
END;
/

The following PHP calls the procedure and returns the value. It uses the required connection syntax for the Zend Server Community Edition.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

<?php
  // Attempt to connect to your database.
  $c = @oci_connect("student", "student", "localhost/xe");
  if (!$c) {
    print "Sorry! The connection to the database failed. Please try again later.";
    die();
  }
  else {
    // Initialize incoming message whether or not parameter sent.
    $msg_in = (isset($_GET['msg'])) ? $_GET['msg'] : "Cat got your keyboard?";

    // Set the call statement, like a SQL statement.
    $sql = "BEGIN echo(:a,:b); END;";

    // Prepare the statement and bind the two strings.
    $stmt = oci_parse($c,$sql);

    // Bind local variables into PHP statement, you need to size OUT only variables.
    oci_bind_by_name($stmt, ":a", $msg_in);
    oci_bind_by_name($stmt, ":b", $msg_out, 80, SQLT_CHR);

    // Execute it and print success or failure message.
    if (oci_execute($stmt)) {
      print $msg_out;
    }
    else {
      print "Sorry, I can't do that Dave...";
    }
    // Free resources.
    oci_free_statement($stmt);
    oci_close($c);
  }
?>

You can then test it with or without a parameter, like this example with a parameter:

http://localhost/message_reply.php?msg="Sample message"

I put a link in the forum to this, and I hope it helps a few folks.

I got all the screen shots out last night, then I realized that the configuration instructions were missing. They’ve been added now, and you can check if you’re interested.

In the process, I noticed that Zend Server Community Edition is using connection pooling by default with Oracle. This means that the TNS alias must be qualified by a hostname.

For example, on your local PC with Oracle Database 10g Express Edition, the default TNS alias is XE. You can’t use that anymore when you’re running the Zend Server. You must qualify it as localhost/XE or hostname/XE as the connection string. A natural alternative is to insert a fully qualified TNS network map

Here are three possible connection patterns:

1
2
3
4
5
6
7
8
9
10
11
12

<?php
  // Attempt to connect to your database.
  $c = @oci_connect("student", "student", "localhost/xe");
  if (!$c) {
    print "Sorry! The connection to the database failed. Please try again later.";
    die();
  }
  else {
    print "Congrats! You've connected to an Oracle database!";
    oci_close($c);
  }
?>

02-JUL-2009 23:32:11 * (CONNECT_DATA=(SERVICE_NAME=xe)(CID=(PROGRAM=C:\Program?Files\Zend\ZendServer\bin\php-cgi.exe)(HOST=MCLAUGHLINXP32)(USER=SYSTEM))) * (ADDRESS=(PROTOCOL=tcp)(HOST=127.0.0.1)(PORT=1405)) * establish * xe * 0

1
2
3
4
5
6
7
8
9
10
11
12

<?php
  // Attempt to connect to your database.
  $c = @oci_connect("student", "student", "hostname/xe");
  if (!$c) {
    print "Sorry! The connection to the database failed. Please try again later.";
    die();
  }
  else {
    print "Congrats! You've connected to an Oracle database!";
    oci_close($c);
  }
?>

02-JUL-2009 23:29:16 * (CONNECT_DATA=(SERVICE_NAME=xe)(CID=(PROGRAM=C:\Program?Files\Zend\ZendServer\bin\php-cgi.exe)(HOST=MCLAUGHLINXP32)(USER=SYSTEM))) * (ADDRESS=(PROTOCOL=tcp)(HOST=172.16.153.138)(PORT=1403)) * establish * xe * 0

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

<?php
  $tns = "(DESCRIPTION =
              (ADDRESS=(PROTOCOL = TCP)(HOST = mclaughlinxp32)(PORT = 1521))
              (CONNECT_DATA=(SERVER = DEDICATED)(SERVICE_NAME = XE)))";

  // Attempt to connect to your database.
  $c = @oci_connect("student", "student", $tns);
  if (!$c) {
    print "Sorry! The connection to the database failed. Please try again later.";
    die();
  }
  else {
    print "Congrats! You've connected to an Oracle database!";
    oci_close($c);
  }
?>

02-JUL-2009 23:27:10 * (CONNECT_DATA=(SERVICE_NAME=XE)(CID=(PROGRAM=C:\Program?Files\Zend\ZendServer\bin\php-cgi.exe)(HOST=MCLAUGHLINXP32)(USER=SYSTEM))) * (ADDRESS=(PROTOCOL=tcp)(HOST=172.16.153.138)(PORT=1401)) * establish * XE * 0

I’m sure it was in the documents but then again, I didn’t read them.

The Zend Core Server replaces the deprecated Zend Core for Oracle. I’ve put a quick installation guide here. It’s much nicer, and the licensed server is now the recommended direction from Oracle.

The community edition also installs MySQL, phpMySQLAdmin, and a brand new console. You should try it out.

I finally got around to summarizing how to use PHP to store, retrieve, and display CLOBs and BLOBs from an Oracle database. I think too often we default to BFILEs. I put all the code in zip files with instructions and suggestions for locations. This is really the second entry that goes with configuring Zend Server Community Edition or the DEPRECATED Zend Core for Oracle.

If you’re new to PHP, check out the Underground PHP and Oracle book from Christopher Jones and Alison Holloway. It’s FREE!

The Oracle LOB Processing entry is in this blog page. I know it means another click, but I’ll probably add and modify it over time. If you’ve got time and interest, take a look and let me know what you think and what improvements you’d like to see. Thanks.

I finally got around to creating a blog page that shows you how to install Zend Core for Oracle, verify the installation of PHP, your connection to an Oracle XE database with PHP, and your connection to a MySQL database with PHP.

It’s using the folding concepts I’ve adopted in the blog. One section unfolds to display screen shots for the installation of Zend Core for Oracle. Another section shows you how to confirm your PHP and Apache installation. Two other sections show you how to confirm your connection to an Oracle or MySQL database.

I apologize to those who don’t like to click through to another page, but it was a long page with 20+ images. Hope it helps a few folks, I know it’ll help my students.

Somebody felt that I’d short changed Oracle by providing only an example for calling a stored procedure in MySQL. So, here’s an equivalent post to the MySQL sample that works in an Oracle database with PHP.

The largest difference between the two approaches is that Oracle is transactional by default while MySQL isn’t. However, the use of savepoints and rollbacks are shown in the procedure, which are the appropriate transaction controls in Oracle.

Here are the detailed steps, even though there are other blog entries with information on related subjects.

1. Sign on as the system user, and create a new user. Users in Oracle have their own schema or work area, and they don’t require a database like MySQL or SQL Server.

SQL> CREATE USER student IDENTIFIED BY student;
SQL> GRANT connect, resource, CREATE any VIEW TO student;

2. Create a create_oracle_procedure.sql file with the following contents:

-- Conditionally drop the objects to make this rerunnable.
BEGIN
  FOR i IN (SELECT table_name
            FROM   user_tables
            WHERE  table_name IN ('A','B')) LOOP
    EXECUTE IMMEDIATE 'DROP TABLE '||i.table_name||' CASCADE CONSTRAINTS';
  END LOOP;
  FOR i IN (SELECT sequence_name
            FROM   user_sequences
            WHERE  sequence_name IN ('A_SEQ','B_SEQ')) LOOP
    EXECUTE IMMEDIATE 'DROP SEQUENCE '||i.sequence_name;
  END LOOP;
END;
/

-- Create the tables and sequences.
CREATE TABLE a
( a_id   NUMBER CONSTRAINT a_pk PRIMARY KEY
, a_text VARCHAR2(12));

CREATE SEQUENCE a_seq;

CREATE TABLE b
( b_id   NUMBER CONSTRAINT b_pk PRIMARY KEY
, a_id   NUMBER
, b_text CHAR(12)
, CONSTRAINT fk_a FOREIGN KEY(a_id) REFERENCES a (a_id));

CREATE SEQUENCE b_seq;

-- Create a stored procedure.
CREATE OR REPLACE PROCEDURE double_insert
( input_a VARCHAR2, input_b VARCHAR2) IS
BEGIN
  SAVEPOINT starting_point;
  INSERT INTO a VALUES (a_seq.NEXTVAL, input_a);
  INSERT INTO b VALUES (b_seq.NEXTVAL, a_seq.CURRVAL, input_b);
  COMMIT;
EXCEPTION
  WHEN OTHERS THEN
    ROLLBACK TO starting_point;
    RETURN;
END;
/

-- Define a couple local session variables.
VARIABLE text1 VARCHAR2(12)
VARIABLE text2 VARCHAR2(12)

-- Assign values to session variables.
BEGIN
  :text1 := 'This is one.';
  :text2 := 'This is two.';
END;
/

-- Call the local procedure.
EXECUTE double_insert(:text1,:text2);

-- Select the data set.
SELECT * FROM a;
SELECT * FROM b;

3. Quit the session as the system user. You can simply reconnect to the new schema like this:

SQL> CONNECT student/student@orcl

4. Run the file from the relative directory where you started the sqlplus executable.

SQL> @create_oracle_procedure.sql

You see the following query results at the end of the script:

      A_ID A_TEXT
---------- ------------
         1 This IS one.


      B_ID       A_ID B_TEXT
---------- ---------- ------------
         1          1 This IS two.

5. Write the following into a call_oracle_procedure.php:

<?php
  // Attempt to connect to your database.
  $c = @oci_connect("student", "student", "orcl");
  if (!$c) {
    print "Sorry! The connection to the database failed. Please try again later.";
    die();
  }
  else {
    // Declare two variables for the test procedure call.
    $val1 = "Hello Hal!";
    $val2 = "Hello Dave!";

    // Set the call statement, like a SQL statement.
    $sql = "BEGIN double_insert(:a,:b); END;";

    // Prepare the statement and bind the two strings.
    $stmt = oci_parse($c,$sql);

    // Bind local variables into PHP statement.
    oci_bind_by_name($stmt, ":a", $val1);
    oci_bind_by_name($stmt, ":b", $val2);

    // Execute it and print success or failure message.
    if (oci_execute($stmt)) {
      print "Congrats! You've executed a Oracle stored procedure from PHP!";
    }
    else {
      print "Sorry, I can't do that Dave...";
    }
    // Free resources.
    oci_free_statement($stmt);
    oci_close($c);
  }
?>

6. Run the call_oracle_procedure.php from the command line, like this:

php call_oracle_procedure.php

7. Now you can requery the database to see the inserts made by the PHP program.

SQL> SELECT * FROM a;

      A_ID A_TEXT
---------- ------------
         1 This IS one.
         2 Hello Hal!

SQL> SELECT * FROM b;

      B_ID       A_ID B_TEXT
---------- ---------- ------------
         1          1 This IS two.
         2          2 Hello Dave!

There’s now a sample file for both approaches. As always, I hope this helps some folks.
